This lessons focuses on the different types of docker volumes and their behaviors along with some gotchas

Reference: https://docs.docker.com/engine/storage/volumes/

What is docker volumes?

#

So we have docker volumes to persist data between and away from containers, meaning if our container is pruned or deleted the data within it is not deleted along with the container.

But also we use it to pass in our data into the container, maybe config files or media files etc.

Creation:

#

• Automatic
• docker volume create

Usage:  docker volume COMMAND

Manage volumes

Commands:
  create      Create a volume
  inspect     Display detailed information on one or more volumes
  ls          List volumes
  prune       Remove all unused local volumes
  rm          Remove one or more volumes

Docker volumes are managed by docker.

Why/When use volumes?

#

• Volumes are easier to back up or migrate than bind mounts.
• You can manage volumes using Docker CLI commands or the Docker API.
• Volumes work on both Linux and Windows containers.
• Volumes can be more safely shared among multiple containers.
• New volumes can have their content pre-populated by a container or build.
• When your application requires high-performance I/O.

General Behavior

#

Do this

• Use volumes to store data, they are faster and do not increase container size.

Don’t do this

• Don’t write data directly inside the container filesystem, it slows performance and increases container size due to the storage driver and union filesystem.

Basically, writing changes to a volume is faster then writing changes to a file inside the container

Single volume can be mounted on multiple containers ie sharing the same volume writing and all

• If a non-empty volume is mounted to a container path, the volume files are shown and any existing container files at that path are hidden.

• If an empty volume is mounted to a container path that already contains files, Docker copies the container files into the volume, and then mounts it.

• Copying occurs only when the volume is empty. If the volume is not empty, Docker performs masking, not copying.

• If a non-empty volume is mounted to a non-existent container path, Docker creates the path and the volume contents appear inside the container.

Types of Docker Volumes

#

1. Named volumes:

#

(if name not provided then anonymous volumes)

--rm can be used to supersede the default behavior of maintaining a container after a docker run. It will remove the volume once container is deleted

docker run --mount type=volume,src=<volume-name>,dst=<mount-path>
docker run --volume <volume-name>:<mount-path>

Options for Volume:

docker run -v [<volume-name>:]<mount-path>[:opts]

Example:

docker run -it -v config_vol:/etc/myconfig:ro ubuntu

This runs an ubuntu image in an interactive shell that mounts a named volume at the /etc/myconfig directory in the container.

ro - is read only, so the files inside the container cannot be overwritten but file at the volume location can

The folder is created if it doesnt exists already

2. Bind Mounts

#

A bind mount mounts a file or directory from the host machine into a container. Unlike volumes, Docker does not manage the data, changes are reflected directly on the host.

When to use

#

• Share source code or build artifacts between host and container.

• Persist files created in a container to the host filesystem.

• Share configuration files like /etc/resolv.conf.

• Bind mounts can also be used during builds to test, lint, or compile code.

Behavior

#

• Mounting over an existing container directory hides existing contents.

• Containers are tightly coupled to the host’s directory structure.

• Default access is read-write, but can be made read-only (:ro or :readonly).

• On Docker Desktop, bind mounts are translated to the VM filesystem if using Linux containers.

Syntax

#

Using --mount (preferred)

#

docker run --mount type=bind,source=<host-path>,target=<container-path>[,ro,bp-option]

• source / src: host path

• target / dst: container path

• ro: read-only

• bind-propagation: rprivate, rshared, etc.

Example:

docker run -d -it --name devtest --mount type=bind,source="$(pwd)"/target,target=/app,readonly nginx:latest

Using -v or --volume

#

docker run -v <host-path>:<container-path>[:opts] <image>

Example:

docker run -d -it --name devtest -v "$(pwd)"/target:/app:ro,rshared nginx:latest

Notes

#

• Verify mount with docker inspect devtest → check Mounts section.

• Stop and remove container if needed:

docker container rm -fv devtest

• Be careful binding into non-empty container directories—it may break the container if critical paths are replaced.

• Use readonly mounts to prevent accidental host changes.

3. tmpfs mounts

#

What are tmpfs mounts

#

• Tmpfs mounts let containers create temporary files outside their writable layer.

• Unlike volumes or bind mounts, data is stored in host memory, not persisted to disk.

• Data is removed when the container stops.

• Best for temporary data for performance or security reasons.

Important Points

#

• Tmpfs maps directly to Linux kernel tmpfs; data may swap to disk.

• Mounting over existing container files hides them; recreating the container is needed to restore.

• Limitations:

  • Cannot share tmpfs between containers.

  • Only works on Linux.

  • Permissions may reset after restart; uid/gid can help.

Docker Syntax

#

–tmpfs flag (simpler, flexible):

docker run --tmpfs <container-path>[:options]

–mount flag (more explicit, preferred):

docker run --mount type=tmpfs,dst=<container-path>[,key=value...]

Options for –tmpfs

#

• ro/rw – read-only / read-write

• nosuid/suid – setuid/setgid enforcement

• nodev/dev – device files behavior

• exec/noexec – executable binaries

• sync/async – synchronous/asynchronous I/O

• size – mount size (e.g., size=64m)

• mode – file permissions

• uid/gid – owner of mount

• nr_inodes/nr_blocks – limits

Example:

docker run --tmpfs /data:noexec,size=1024,mode=1777

Options for –mount

#

• type=tmpfs – defines tmpfs mount

• dst / destination / target – container path

• tmpfs-size – size in bytes

• tmpfs-mode – file mode (octal)

Example:

docker run --mount type=tmpfs,dst=/app,tmpfs-size=21474836480,tmpfs-mode=1770

Usage Example

#

–mount version:

docker run -d -it --name tmptest --mount type=tmpfs,destination=/app nginx:latest

–tmpfs version:

docker run -d -it --name tmptest --tmpfs /app nginx:latest

Verify mount:

docker inspect tmptest --format '{{ json .Mounts }}'

Stop & remove:

docker stop tmptest
docker rm tmptest

Volumes vs Bind Mounts

#

Summary for Different mounting options

#

• tmpfs → fastest, ephemeral, in-memory.

• Bind mounts → fast, host-dependent, for dev or direct host access.

• Named volumes → balanced, persistent, Docker-managed.

• Anonymous volumes → temporary persistence.

• Volume plugins → networked or special storage solutions.

Commands with volumes

#

• Basic volume commands

  • Create: docker volume create my-vol

  • List: docker volume ls

  • Inspect: docker volume inspect my-vol

  • Remove: docker volume rm my-vol

• Using a volume with a container

  • If a volume does not exist, Docker creates it automatically.

  • Example:

    docker run -d --name devtest -v myvol2:/app nginx:latest

  • -v and --mount achieve the same result.

  • Volumes are mounted read-write by default.

• Inspecting volume usage

  • docker inspect <container> shows:

    • Type: volume

    • Source: /var/lib/docker/volumes/<name>/_data

    • Destination: container path

• Removing volumes

  • Stop and remove the container first.

  • Volume removal is a separate step:

    docker volume rm <volume-name>

• Volumes with Docker Compose

  • Volumes are created automatically on first docker compose up.

  • Example:

services:
  frontend:
    image: node:lts
    volumes:
      - myapp:/home/node/app
volumes:
  myapp:

- Reused across subsequent runs.

• Using external volumes in Compose

  • Pre-create the volume:

    docker volume create myapp

  • Reference it as external:

volumes:
  myapp:
    external: true

• Remove anonymous volume:

docker run --rm -v /foo -v awesome:/bar busybox top

Runs the container with volume that is deleted upon container deletion

• Remove all unused volumes:

docker volume prune

Backup and Restoring

#

Docker volumes are persistent and managed by Docker, which makes backing up and restoring relatively straightforward. You can use a temporary container to access the volume’s data.

1. Backup a Volume

#

To back up a volume named my-vol to a tar file on the host:

docker run --rm \
  -v my-vol:/volume-data \
  -v $(pwd):/backup \
  alpine \
  tar czf /backup/my-vol-backup.tar.gz -C /volume-data .

Explanation:

• --rm → removes the temporary container after running.

• -v my-vol:/volume-data → mounts the volume into the container.

• -v $(pwd):/backup → mounts the current host directory to store the backup.

• tar czf ... → compresses the volume data into a tar.gz file.

2. Restore a Volume

#

To restore the backup into a volume (existing or new):

1. Create the volume if it doesn’t exist:

docker volume create my-vol

2. Restore the backup:

docker run --rm \
  -v my-vol:/volume-data \
  -v $(pwd):/backup \
  alpine \
  sh -c "cd /volume-data && tar xzf /backup/my-vol-backup.tar.gz --strip 1"

Explanation:

• --strip 1 removes the top-level directory from the archive if present.

• This restores all files into the volume my-vol.

Notes

#

• You can automate this with scripts for regular backups.

• Make sure no container is writing to the volume during backup to avoid inconsistent data.

Volume Drivers

#

Why storage (volume) drivers

#

• Allow Docker to use external storage systems instead of local disk

• Enable network storage (NFS, CIFS, SFTP, cloud remotes)

• Provide data persistence beyond a single host

• Let Docker delegate mounting to the Linux kernel mount system

• Support block devices and remote filesystems transparently

Types of volume drivers

#

1. Local volume driver (default)

#

Uses the host’s filesystem or kernel-supported mounts.

Example 1

#

Type: Local + NFS

Command:

docker service create \   --mount 'type=volume,source=nfsvolume,target=/app,volume-driver=local,volume-opt=type=nfs,volume-opt=device=:/var/docker-nfs,volume-opt=o=addr=10.0.0.10' \   nginx`

Optimal use case:

• Shared storage across multiple containers or nodes

• Centralized persistent data

• Swarm or multi-host setups

Example 2

#

Type: Local + CIFS (Samba)

Command:

docker volume create \   --driver local \   --opt type=cifs \   --opt device=//server/share \   --opt o=addr=server,username=user,password=pass \   --name cifs-volume

Optimal use case:

• Windows file servers

• NAS devices

• Enterprise network shares

2. Plugin-based volume drivers

#

Extend Docker to support remote or cloud-backed storage.

Example 3

#

Type: rclone (SFTP)

Command:

docker volume create \   -d rclone \   --name rclonevolume \   -o type=sftp \   -o path=remote \   -o sftp-host=1.2.3.4 \   -o sftp-user=user

Optimal use case:

• Remote servers over SSH/SFTP

• Secure off-host backups

• Cloud storage integration

3. Block device volumes

#

Mount raw disks or partitions directly into containers.

Example 4

#

Type: Local + block device (ext4)

Command:

docker run \   --mount='type=volume,dst=/external-drive,volume-driver=local,volume-opt=device=/dev/loop5,volume-opt=type=ext4' \   ubuntu

Optimal use case:

• High-performance I/O

• Direct disk access

• Specialized storage workloads

Key notes (important)

#

• --mount is required when passing driver options

• -v does not support advanced volume options

• Docker forwards volume options directly to the Linux mount syscall

• Volume plugins must be installed before use

• Block device mounting requires host-level access
